When your industrial machinery demands peak performance, precision, and reliability, the gears inside it are doing the heavy lifting — often quite literally. Among all gear types, herringbone gears stand out for their superior load-carrying capacity and smooth operation. But choosing the wrong one can lead to costly downtime, premature wear, and safety risks.
This guide walks you through everything you need to know to select the right herringbone gear for your application — so you make a confident, informed decision the first time.
A herringbone gear (also called a double helical gear) features two sets of helical teeth arranged in a V-shape on the same gear body. This unique design cancels out the axial thrust forces that standard helical gears generate — a major engineering advantage.
Key benefits of herringbone gears include:
They are widely used in steel rolling mills, marine propulsion systems, heavy compressors, mining equipment, and power generation machinery.
Start with your machinery's torque and load data. Herringbone gears excel in high-load, high-torque environments, but you still need to match the gear's rated capacity to your application's peak and continuous load demands.
Ask yourself:
Undersizing a gear leads to premature failure. Oversizing increases cost and weight unnecessarily. Always calculate with a service factor to account for real-world operating conditions.
The module (metric) or diametral pitch (imperial) determines the tooth size and how well gears mesh together. Selecting the right module ensures:
The number of teeth directly affects the gear ratio. For applications requiring significant speed reduction — like conveyors or mills — a higher tooth count difference between the driver and driven gear is needed.
The material of a herringbone gear determines its strength, wear resistance, and suitability for your operating environment.
| Material | Best For |
|---|---|
| Alloy Steel (case hardened) | Heavy-duty industrial, high torque |
| Carbon Steel | Medium-load general applications |
| Cast Iron | Cost-sensitive, lower speed uses |
| Stainless Steel | Corrosive or food-grade environments |
| Bronze/Brass | Low-load, noise-sensitive applications |
For most heavy industrial applications — mining, steel plants, cement mills — case-hardened alloy steel (such as EN36 or EN353) is the preferred choice due to its excellent surface hardness and tough core.
The helix angle of the two opposing sets of teeth typically ranges from 15° to 45°. A higher helix angle offers:
However, manufacturing complexity increases with helix angle. For most industrial applications, helix angles between 20° and 35° offer the best balance of performance and manufacturability.
Herringbone gears require proper lubrication to prevent metal fatigue, pitting, and scoring. Consider:
Always specify your environment clearly when ordering gears — it affects both material choice and surface treatment (such as phosphate coating, nitriding, or carburizing).
At Asar Engineering Pvt. Ltd., we have decades of experience manufacturing precision herringbone gears for some of India's most demanding industrial sectors — including steel, cement, mining, and power generation.
What sets us apart:
✅ Custom-engineered herringbone gears manufactured to your exact specifications
✅ High-quality alloy and carbon steel with full material certifications
✅ In-house gear cutting, grinding, and heat treatment capabilities
✅ Strict dimensional and surface finish quality control
✅ Pan-India delivery with competitive lead times
✅ Technical consultation to help you select the right gear the first time
Whether you need a single replacement gear or a complete gearbox solution, our team of engineers is ready to help.
Choosing the right herringbone gear doesn't have to be complicated. With the right partner, you get gears that perform reliably, last longer, and reduce your total cost of ownership.
